QF SERIES PRODUCTS INFORMATION
SPECIFICATIONS		UNITS	QLN-804	QLN-854	QLN-904B
OVERALL DIMENSIONS (L*W*H)		mm		4285*1915*2750
ENGINE
Brand and Model			YUCHAI/YTO ENGINE
Rated Engine Power		hp/kw	80/59	85/62.5	90/66.2
Type			Direct-injection,water-cooled 4-cylinders diesel engine
Rated Engine Speed		rpm	2300	2300	2300
Rated PTO Power		kw	50.2	53.1	56.3
Fuel Tank Capacity		ltr	80
TRANSMISSION
Clutch			LUK 12in.,dual-function,independent,dry clutch
10F+10R Shuttle Shift			●	●	●
Speed Range		km/h	Forward(3.20～32.80)/Reverse(3.77～38.89)
Differential Lock			●	●	●
BRAKES
Type/Actuation			Single chip, disc, mechanical operation,dry
Parking Brake			Mechanical,Independent of main breaks,Hand lever control
Air Trailer Brake			○	○	○
FRONT AXLE
TYPE			ZF brand,Hydraulic steering
Min.Turning Radius		m	4.2
WORKING DEVICE
3 Point Linkage			CAT.2,Draft,Position adjustable and Floating control
Hydraulic Flow		l/min	55
Lift Capacity at Lift Point		kg	3500
Lift Capacity at 610mm Behind Lift Ends			2000
2/4 Remote Valves			○	○	○
ROPS and CABIN
ROPS			○	○	○
Cabin with Fan/Heater/AC			○	○	○
TIRES AND WEIGHTS
Front Tires	Standard		8.3一24
	Option		8.3一24/9.5一24(Paddy Tyre)
Rear Tires	Standard		14.9一30
	Option		11一32(Paddy Tyre)
Tractor with ROPS Weight(kg)*			3200	3200	3200
Tractor with Cab Weight(kg)*			3480	3480	3480
Front and Rear Ballasts			○	○	○
Color
Key:    ● Standard    ○ Optional   * Tractor Dry Mass
